CPU Socket Intel® LGA 1851 / 1700 / 1200 / 1150 / 1151 / 1155 / 1156
CPU Socket AMD® AM5 / AM4
Radiator Material Aluminum
Radiator Dimensions (240) - 277 x 119.2 x 27 mm (10.9 x 4.7 x 1.1 inch)
Pump Dimensions 92.5 x 87 x 38.5 mm (3.6 x 3.4 x 1.5 inch)
Pump Profiles Addressable Gen2 RGB
Pump Speed 3400 ± 300 RPM
Pump MTTF >210,000 Hours
Pump Noise Level 25 dBA (Max)
Pump Rated Voltage 12 VDC
Pump Power Consumption 3.84 W
Pump Connector 3-Pin ARGB + 4-Pin PWM
Tube Length (240) 350 mm
Tube Length (360) 400 mm
Fan Dimensions (L x W x H) (240) 241 x 122 x 26.5 mm (9.5 x 4.8 x 1 inch)
Fan Dimensions (L x W x H) (360) 361 x 122 x 26.5 mm (14.2 x 4.8 x 1 inch)
Profile Addressable Gen 2 RGB
Fan Quantity 2 PC
Fan Speed 690 ~ 2500 RPM ± 15%
Fan Airflow (240) 240.35 m³/h (141.4 CFM)
Fan Airflow (360) 322.8 m³/h (190 CFM)
Fan Air Pressure 3.61 mmH2O
Fan MTTF >160,000 Hours
Fan Noise Level (240) 36 dB(A)
Fan Noise Level (360) 38.5 dB(A)
Fan Bearing Type Loop Dynamic Bearing
Fan Connector 7-Pin PWM + ARGB
Fan Rated Voltage 12 VDC
Fan Rated Current 0.5 A
Fan Safety Current 0.8 A
Fan Power Consumption 6 W
Radiator Size 240
Radiator Size 360
Cooler Type Liquid Cooler
Series MasterLiquid
LCD Exterior Color Black / White
LCD Dimensions 85 x 79.2 x 18.7 mm (3.4 x 3.1 x 0.7 inch)
LCD Connector USB Type-C to Motherboard 9 pin
LCD Screen Size 2.1 inches / Diameter 53.3 mm
LCD Screen Resolution 480 x 480 px
LCD Screen Luminance 300 cd/m²
LCD Screen Refresh Rate 60 Hz
LCD Screen Orientation Software-MasterCtrl adjustable
LCD Rated Voltage 5 VDC
LCD Rated Current 0.3 A
LCD Safety Current 0.5 A
LCD Power Consumption 1.5 W
Warranty 6 years
